SFW7020-Z large self-instal LED unloading lighting lighthouse

With 4 high-efficiency energy-saving lamp heads, the exposure angle can be adjusted alone up, down, left and right, the lighting is high, the coverage range is large, and the lighting is long and near. It is particularly suitable for large outdoor work lighting.The lighthouse lifting rod is refined by high-intensity alloy materials, which can achieve aerodynamic lifting adjustment, and the maximum rise height is 10 meters.

Product Documentation

Scope

In Order to meet the neededs of Railway, Power, Public Security, Fire, Municipal, Bridge, Tunnel and Other Industries, The Construction Operation Lighting, And Develop and Producesfw7020Z large self-installed unloading lighting lighthouse, suitable for various large-scale construction operations, Large-area and high brightness lighting on the spot.It is suitable for maintaining large-scale lighting such as repair, accident treatment, flood prevention, flood resistance, and rescue disaster relief.


Features

█ uses 4 high-efficiency energy-saving lamp heads, with high illumination, high coverage, and large-scale lighting. The light source life is more than 10,000 hours, which is especially suitable for large outdoor work lighting.

█ The lighthouse lifting rod is refined by high-intensity alloy materials, which can achieve pneumatic lifting adjustment, and the maximum rise height is 10 meters; the four lamp heads can adjust the lighting angle alone up, down, left, right, and the light covers the work site.

█ Use imported high-performance power generation units to supply power. In a place with municipal electricity, 220V AC power supply can also be connected to achieve long-term lighting.

█ Remote control or point-to-point switch controls the lifting and downstream of the lifting rod, and the operation is simple, safe and reliable; wireless remote control method can control the lifting and downward of the lift rod within 30 meters.

█ The lighthouse as a whole is made of a variety of high-quality alloy materials. It has a compact structure and stable performance. It can work normally under various harsh environments and climatic conditions. The wind resistance level is 8 levels.

█ Optimized structural design, convenient movement and connecting to the trailer can be convenient to move to any construction or rescue site.

█ can adjust at the number of lamp heads, power, pan-light or concentration type, the height of the lifting rod and the equipment of the generator according to customer requirements to meet the personalized needs of customers.


Technical parameter

Parameter name

Value

model

SFW7000-H

Main light lighting power

2700W

Auxiliary lighting

2×28W

Light source

LED

Foot loading and unloading/development method

DC electric

Loading time

180S

Lighthouse lifting method

pneumatic

Lighthouse lifting height

7M

Protection level

IP65

Lighting angle angle

45 degrees

Maximum expansion width

2.1 meters

Maximum distance

1.1 meters

Way of operation

Integrated panel control

Generator

Honda generator

Fuel tank capacity

50L

The generator is filled with fuel continuous working hours at a time

28h

Appearance

1400×1800×2100mm

weight

650KG
